HD2000 IP User Manual
Copyright © 2015 SAS HENRI DEPAEPE Page 8 of 52
5.2. Walls mount installation:
The HD2000 IP comes with a small plastic bag containing 1 thins screw and a foam plug to be
used for preventing theft or unauthorized removal, 2 bigger screws for wall mount fixing.
1) Drill 2 holes as shown on the wall mounting layout (see the next drawing). Install the 2
bigger screws in those holes on the wall.
