HD2000 IP User Manual
Copyright © 2015 SAS HENRI DEPAEPE Page 36 of 52
Network -Advanced
Options
Meaning
LLDP
Active : select the desired value from the pull-down list of Active.
Packed interval : enter the desired time(in seconds) in the Packet
interval (1~3600s) field.
Qos Set
Layer 3 Qos : This field defines the layer 3 QoS parameter which can
be the value used for IP Precedence or Diff-Serv or MPLS. Default
value is 48.
Layer 2 Qos : Value used for layer 2 VLAN tag. Default setting is
blank.
Data VLAN Tag : Valid only when bridge mode.
VPN
Active :
Upload VPN Config :
DHCP VLAN
Active : yes or no (DHCP option 132)
Web Server
HTTP Port : default for http is 80.
HTTPS Port :
Type :
802.1X
802.1X Mode :
Identily :
MD5 Password :
Local RTP Port
Max Rtp Port : The Largest RTP Port : Should be large than
(Min-RTP-Port +100) and less than 65535.
Min Rtp Port : The Lowest RTP Port : Port>= 1024
VQ RTCP Report
RTCP Support : If Enable, Phone will statistic analysis RTP Info,
Then Report to Collector if Need.
Voice Quality Report Collector : The RTCP Collector Info, e.g :
sip:account@sample.com:8765.
RTCP-XR-report Format : The Format of Reported PUBLISH Info
Others
STUN Server : URI or IP:port
Keep-alive interval : default 20 seconds.
