116035-01J 49
PARTS
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 45 of this manual.
DESCRIpTION
1 116317-01 Remote Ignitor Bracket • • • • • • 1
2 114886-01 Door Retainer Bracket • • • • • • 1
3 108085-01 Pilot Orice #51 • • 1
108085-02 Pilot Orice #30 • • 1
108085-03 Pilot Orice #62 • • 1
4 108084-02 Pilot Assembly • • 1
108084-05 Pilot Assembly • • 1
108084-03 Pilot Assembly • • 1
5 27206 Burner Orice #44 • • • • 1
26482 Burner Orice #55 • • 1
6 26808 Valve Bracket • • • • • • 1
7 24389 Tube 3/8" Dia. x 11" Aluminum • • • • • • 1
8 24360 Pilot Bracket • • • • • • 1
9 14500 Fitting 3/8" MPT x 1/2” Flare • • • • • • 1
10 14399 Fitting Brass Elbow 3/8" MPT x 3/8"
Comp. Tube
• • • • • • 1
11 14396 Fitting Brass Straight 3/8" MPT x 3/8”
Comp. Tube
• • • • • • 1
12 14389 Gas Control Valve Millivolt • • 1
117370-01 Gas Control Valve Millivolt • •
14390 Gas Control Valve Millivolt • • 1
13 14299 Air Shutter • • • • • • 1
14 14261 Ignitor Piezo • • • • • • 1
15 11226 Washer, Flat 7/8" ID x 2" OD x 1/8" Thick • • • • • • 2
16 11214 Fitting Bulkhead w/ Nut Brass • • • • • • 1
17 11187 Screw, #8 x 1/4" PPH • • • • • • 1
18 11107 Screw, #10-32 x 1/4" PPH Zinc • • • • • • 4
19 11105 Screw, #10 x 1/2" HWH LGM Zinc • • • • • • 10
20 11102 Screw, #8 x 3/8" PPH F Zinc • • • • • • 2
To Next Page
