  DESCRIpTION 
1 116719-01 Gas Valve Wire Harness (MV/PV) • • • • 1
2 116719-02 Gas Valve Wire Harness (MV) • • • • 1
3 116719-03 Gas Valve Wire Harness (PV) • • • • 1
4 116316-01 Ignition Module Bracket • • • • 1
5 114886-01 Door Retainer Bracket • • • • 1
6 111059-03 Ground Wire Harness • • • • 1
7 110286-01 Ignition Module Synetek • • • • 1
8 108863-01 Plug 24” Supply Connect • • • • 1
9 108867-01 Pilot Orice BL14LP • • 1
108867-02 Pilot Orice BL22N • • 1
10 108866-01 Pilot Assembly PSE • • 1
108866-02 Pilot Assembly PSE • • 1
11 27206 Burner Orice #44 • • 1
26482 Burner Orice #55 • • 1
12 26808 Valve Bracket • • • • 1
13 24389 Tube 3/8" Dia. x 11" Aluminum • • • • 1
14 24360 Pilot Bracket • • • • 1
15 14569 Gas Control Valve Millivolt • • 1
14570 Gas Control Valve Millivolt • • 1
16 14500 Fitting 3/8" MPT x 1/2” Flare • • • • 1
17 14399 Fitting Brass Elbow 3/8" MPT x 3/8" Comp. Tube • • • • 1
18 14396 Fitting Brass Straight 3/8" MPT x 3/8" Comp. Tube • • • • 1
19 14299 Air Shutter • • • • 1
20 14129 Transformer, 24V Class 2 • • • • 1
21 11404 Cable, Tie 8.5” #10 Screwdown • • • • 1
22 11226 Washer, Flat 7/8" ID x 2" OD x 1/8" Thick • • • • 2
23 11214 Fitting Bulkhead w/ Nut, Brass • • • • 1
24 11201 Nut, #8-32 Hex Zinc • • • • 4
25 11186 Screw, #8-32 x 1” PPH • • • • 2
26 11187 Screw, #8 x 1/4" PPH • • • • 1
27 11109 Screw, #8-32 x 1/2” PPH • • • • 2
28 11107 Screw, #10-32 x 1/4" PPH Zinc • • • • 4
29 11105 Screw, #10 x 1/2" HWH LGM Zinc • • • • 11
30 11102 Screw, #8 x 3/8" PPH F Zinc • • • • 2
PARTS


This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 45 of this manual.
   
