108660-01E 27
PARTS LIST
MODELS P324 AND VP324
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 25 of this manual.
**Not a eld replaceable part.
KEY
NO. PART NO. DESCRIPTION QTY.
1 ** Insulation Pan 1
2 108403-02 Fireplace Top Assembly 1
3 ** Fireplace Surround 1
4 108425-01 Air Rod Retainer 1
5 108423-01 Panel Closure 2
6 ** Firebox Bottom 1
7 108410-01 Firebox Surround 1
8 108411-01 Air Separator 1
9 106827-01 4" Gasket 1
10 108416-01 4" Collar 1
11 108769-03 Extension Deector 1
12 108428-03 Bottom Front Refractory, Std. Brick 1
13 108426-03 Bottom Rear Refractory, Std. Brick 1
14 106683-01 Firebox Support Leg 2
15 24353 Box Assembly 1
16 108701-01 Screen Rod 2
17 ** Firebox Top Assembly 1
18 108415-01 Starter Pipe Collar 1
19 106703-02 Damper Door Assembly 1
20 ** Firebox Face 1
21 108412-01 Smoke Deector 1
22 ** Fireplace Top Insulation 1
23 109797-01 Grate Assembly 1
24 109107-01 Burner Assembly (see page 30) 1
25 14512 Gas Control Valve (Natural Gas) 1
14513 Gas Control Valve (Propane/LP) 1
26 107741-02 Valve Bracket 1
27 14261 Piezo Ignitor 1
28 108368-01 3/8" Flex Line 1
29 11107 Screw, #10-32 x 1/4 PPH 4
30 108005-04 Wire Harness 1
31 11418 Push-On Nut 2
32 108440-01 Screen 2
33 14123 Strain Relief 1
34 14574 Limit Switch 1
35 22912 Draft Divertor 1
36 14253 Flexible Supply Line w/ Shutoff Valve 1
37 20042 Air Kit Cover 1
38 20088 Door Stop 1
39 20089 Pivot Clip 2
40 20090 Spring Clip 2
41 21171 Gas Knockout Cover 4
42 108652-01 Gas Conduit Assembly, Left 1
43 108654-01 Gas Conduit Assembly, Right 1
44 20280 Top Spacer 4
PARTS AVAILABLE NOT SHOWN
901155-01 Vermiculite Bag 1
901156-01 Pan Material 1
901157-01 Lava Rock 1
22180 Wall Switch Kit 1
