3
INSTALLATION, Cont.
Baby Tray Installation
Before using the scale, it will be necessary to install the baby tray and batteries. Note that the
baby tray is designed to lock into place on the scale weighbridge preventing accidental
separation from the scale.
Follow the steps listed below to install the baby tray. Refer to figure No. 3.
Step 1 Place the scale on a table top.
Step 2 Position the baby tray onto the weighbridge.
Step 3 Slide the baby tray onto the weighbridge until you hear the release knob “click”.
Step 4 Verify the baby tray is locked in place by making certain that it cannot be slide to
the left or right.
CAUTION! Make absolutely certain that the baby tray is locked in place before
using the scale. Be sure that the locking knob is in the locked position.
Failure to lock the baby tray in place can result in injury to the baby should
the tray separate from the scale.
Figure No. 3
To remove baby tray from scale, pull Release Knob and slide tray off weighbridge.
Baby Tray
Measuring Tape
Pull Out
Release Knob
Weighbridge
Level Bubble
Release Knob in
Locked Position
