8555-M512-O1 Rev E y MedVue MV1 Owner’s 10
KEYPAD FUNCTIONS
DO NOT operate the keypad with pointed objects (pencils, pens, etc.).
Damage to keypad resulting from this practice is NOT covered under warranty.
Figure No. 7
This is the ON/OFF key. With the MV1 off, pressing this key will turn it on.
If the MV1 is already on, pressing the key will turn it off.
Basic Functions
This is the ZERO key. It is used to reset the display to zero up to the selected
limit of either 4% or 100% of the scale capacity. The zero limit is set during
setup and calibration of the MV1.
This is the PRINT key. It is used to signal completion of the data entry,
process the data entered, and to send the weight and associated data to the
USB port, RS232 serial port, the optional Ethernet port, and the optional Wi-Fi
and Bluetooth.
NOTE: The MV1 will not respond to pressing the PRINT key unless the weight
display is stable. If displaying gross weight, only the gross weight is printed. If
displaying net weight, the gross, tare, and net weights are printed. If the ID and
BMI features are used, their data is printed along with the weight data.
