8555-M512-O1 Rev E y MedVue MV1 Owner’s 24
CALIBRATION SETUP, CONT.
Navigation Keys, Cont.
ID/HEIGHT – (Next Menu or Parameter)
If at the menu level, this will take you to the previous menu item in the list
below. If SCALE is currently displayed and the setup has been accessed
through the calibration switch, then this will return you to TIME SETTINGS. If
setup has been accessed through setup review, then pressing this when
SYSTEM is displayed will return you to TIME SETTINGS. If at the parameter
level, the exact item this takes you to may depend on a [parameter condition].
PRINT – (Go up a level)
If at the parameter level, this returns you to the menu level. If at the menu
level, this returns you to normal operation
ENTER – (Go into Menu or save Parameter)
If at the menu level, this will take you to the first parameter in the currently
displayed menu in the list below. If at the parameter level, this will store the
currently displayed value for that parameter and proceed to the next parameter
in the list below, which may depend on a [parameter condition].
Numeric Keys
The Numeric Keys are used to input values for the Calibration
Setup parameters. Some parameter prompts require only a yes
or no selection, while others require a numeric value to be
entered.
NOTE: The 1 and 0 keys have dual functions. They are used to
enter numeric values as well as to select no (0 = NO) or yes (1 =
YES) to various prompts.
Calibration Setup Menu
SCALE
Scale Configuration. Proceed to the Scale Capacity parameter.
ZERO
Configure Zero functions. Proceed to the Zero Limit parameter.
FILTER
Analog to Digital Filtering. Proceed to the Filter Mode parameter.
CALIbRATION
Perform Calibration. Proceed to the Calibrate parameter.
GRAVITY
Gravity Constant Function. Proceed to the Enable Gravity parameter.
LOCK
Lock/Release feature. Proceed to the Hold Mode parameter.
SYSTEM
Operational Selections. Proceed to the Language parameter.
SERIAL PORT
Serial I/O Configuration. Proceed to the RS232 Mode parameter.
USb PORT
USB Port Configuration. Proceed to the USB Mode parameter.
bLE/WIFI
Bluetooth/Wi-Fi Configuration. (Displayed if Redbird module is
present). Refer to the Setup and Operation Manual for MedVue
Medical Weight Analyzer with Wi-Fi and Bluetooth, 8555-0550-0M.
ETHERNET
Ethernet Configuration. (Displayed if the MVIP option is present).
Refer to the Model MVIP Ethernet Option Operation Manual,
8555-M520-O1.
TIME SETTINGS
Time and Date Configuration. Proceed to the Year parameter.
To Next Page
