Detecto SlimPRO User Manual

8525-M336-O1 Rev C y SlimPRO Operation
6
BLUETOOTH FUNCTIONS
Bluetooth Pairing
To pair a Bluetooth-capable device with the scale, select the name of the scale
“Chipsea-BLE” from the list of available connections.
Weight Data
GATT Service ID: 0000fff0-0000-1000-8000-00805f9b34fb
Characteristic ID: 0000fff1-0000-1000-8000-00805f9b34fb (Need to subscribe to get data)
0 1 2 3 4 5 7 to 19
Packet
Header
Data
0xFA 0x04
(Temporary
Weight) or
0x05
(Lock
weight)
Abnormal
information:
0. Normal
weighing
1. Overload
2. Minus value
3. Low battery
warning
4. Auto Zero
Units
0 – KG
1 – LB
Decimal place
0 – No decimal
1 – 1 decimal
point
2 – 2 decimal
point
Weight (high bit
in front, low bit
after)
Not
used
