8525-M336-O1 Rev C y SlimPRO Operation
1
FEATURES
Capacity: 600 lb x 0.1 lb / 272 kg x 0.1kg
Weight Indication
Display:
Voice:
Four-digit, seven segment LCD, 1.4 in / 36 mm high digits with
blue backlight
English, Spanish, French, Arabic, Hindu, Chinese, OFF
Indicators:
Weight, Height, BMI Calculation, Low Battery, Mother and Baby
Mode
Functions: Mother and Baby weighing mode
Baby weight starts from 2.2 lb (1 kg)
Auto-ON requires minimum weight of 11 lb (5 kg)
Auto-OFF (approximately 5 seconds)
Unit: lb/kg, selected by switch on bottom of scale
BMI calculation
Manual Input Height (75 cm to 225 cm with 1 cm)
Interface: Bluetooth Low Energy (BLE) 4.0
Power: Four (4) “AAA” Batteries (included)
UNPACKING
Before using your scale, make certain the scale has been received in good condition. When
removing the scale from its packing, inspect it for signs of damage, such as exterior dents
and scratches. Keep the carton and packing material for return shipment if it should become
necessary. It is the responsibility of the purchaser to file all claims for any damages or loss
incurred during transit.
POWER-UP INITIALIZATION
1. Turn the scale over and locate the removable panel on
the bottom of the scale.
2. Remove the panel by pushing in on the tab and lifting
it up to access to the battery holder.
3. Install the included four (4) “AAA” size alkaline or
carbon zinc batteries, noting the polarity markings
located in the battery holder.
4. After placing all four (4) batteries in the holder, replace
the panel.
5. Place the scale on a flat level surface, such as a desk,
table or bench.
6. Lightly press on the scale to turn it on.
7. The scale display will show 6666, then change to a
moving 6, and turn off. If not, remove the panel and
check for one or more improperly positioned batteries.
8. The scale has completed initialization and is ready for
operation.
+
-
+
-
-
+
-
+
Push tab in and lift
