Dettson C45-1-D - Page 45

45
Table 25: Part list – 2 Stage, ECM
#
Description
C45-2-V
C60-2-V
C75-2-V
C105-2-V
C120-2-V
1
Heat exchanger assembly
B40508-03
B40508-04
B40508-05
B40508-07
B40508-08
2
Back panel assembly
B40511-04
B40511-05
B40511-05
B40511-06
B40511-06
3
Right panel assembly
B40510-34
B40510-34
B40510-34
B40510-34
B40510-34
4
Loose part bag
B40569-01
B40569-02
B40569-02
B40569-02
B40569-02
5
Hose 5/8
B30157-34
B30157-34
B30157-34
B30157-34
B30157-34
6
Hose 1/2
B30157-38
B30157-38
B30157-38
B30157-38
B30157-38
7
Hose 3/16
B30157-40
B30157-40
B30157-40
B30157-40
B30157-40
8
Floor
B40546-01
B40546-02
B40546-02
B40546-03
B40546-03
9
Blower assembly
B40604-03
B40604-04
B40604-05
B40604-07
B40604-08
10
Electric blower kit
B40581-01
B40581-01
B40581-01
B40581-02
B40581-02
11
Electric blower kit
B03242-04
B03242-04
B03242-04
B03242-05
B03242-05
12
Separator assembly
B40513-01
B40513-02
B40513-03
B40513-05
B40513-06
13
Inducer restrictor
B40563-07
B40563-04
B40698
N/A
N/A
14
Pressure switch assembly
B40675-19
B40675-20
B40675-21
B40675-23
B40675-24
15
Gas valve
R01I003
R01I003
R01I003
R01I003
R01I003
16
Control card assembly
B40695
B40695
B40695
B40695
B40695
17
Lower door assembly
B40570-07
B40570-08
B40570-08
B40570-09
B40570-09
18
Upper door assembly
B40571-01
B40571-02
B40571-02
B40571-03
B40571-03
19
Left pannel assembly
B40509-02
B40509-02
B40509-02
B40509-02
B40509-02
20
Elect. Kit inverter blower
B40592-01
B40592-01
B40592-01
B40592-02
B40592-02
21
Elect. Kit principal harness
B40593-01
B40593-01
B40593-01
B40593-02
B40593-02
22
Complete gas manifold assembly
B40514-03
B40514-04
B40514-05
B40514-07
B40514-08
23
ID blower assembly
B40578-05
B40578-02
B40578-02
B40578-02
B40578-02
24
Top panel assembly
B40512-01
B40512-02
B40512-02
B40512-03
B40512-03
25
Blower rail
B40552
B40552
B40552
B40552
B40552
26
Door switch
L07H001
L07H001
L07H001
L07H001
L07H001
27
Observation port w Dettson logo
B40565
B40565
B40565
B40565
B40565
28
Observation port
L04Z022
L04Z022
L04Z022
L04Z022
L04Z022
29
Grommet
G14F017
G14F017
G14F017
G14F017
G14F017
30
Pressure switch support
B40560
B40560
B40560
B40560
B40560
31
Pressure switch (condensate box)
R99F035
R99F035
R99F035
R99F035
R99F035
32
Pressure switch (high fire)
R99F043
R99F042
R99F048
R99F039
R99F041
33
Pressure switch (low fire)
R99F039
R99F050
R99F050
R99F050
R99F050
34
Drain trap gasket
B40568
B40568
B40568
B40568
B40568
35
PVC pipe
B40571-02
B40571-01
B40571-01
B40571-01
B40571-01
36
Drain trap
B40535
B40535
B40535
B40535
B40535
37
Venting flange gasket
B40567
B40567
B40567
B40567
B40567
38
Venting flange
B40533
B40533
B40533
B40533
B40533
39
Igniter
R03K005
R03K005
R03K005
R03K005
R03K005
40
Roll out switch
R02N022
R02N022
R02N022
R02N022
R02N022
41
Gas manifold assembly
B40527
B40528
B40529
B40531
B40532
42
Orifice #48 natural gas
R04I001
R04I001
R04I001
R04I001
R04I001
43
Flame detector
R03J004
R03J004
R03J004
R03J004
R03J004
44
Clamp 5/8
G99Z035
G99Z035
G99Z035
G99Z035
G99Z035
45
Elbow 5/8
G07J007
G07J007
G07J007
G07J007
G07J007
46
Condensate box
B40526-01
B40526-02
B40526-02
B40526-03
B40526-04
47
High limit
R02N026
R02N024
R02N023
R02N024
R02N024
48
Baffle
B40572
B40572
B40572
B40572
B40572
49
Smoke box
B40539-01
B40539-02
B40539-02
B40539-03
B40539-04
50
Rubber collar for venting
B40580
B40580
B40580
B40580
B40580
51
ID blower
Z01K006
Z01K006
Z01K006
Z01K006
Z01K006
52
Elbow 1/2
G07J006
G07J006
G07J006
G07J006
G07J006
53
Clamp 1/2
G99Z034
G99Z034
G99Z034
G99Z034
G99Z034
54
Inductance
B03141-02
B03141-01
B03141-01
B03141
B03141
55
Motor assembly ECM (EON 5.0)
B03240-12
B03716-02
B03716-03
B03241-09
B03241-10
56
Motor ECM (EON 5.0)
B03811-25
B03812-09
B03812-10
B03813-15
B03813-16
57
Motor mounting bracket
B01889
B01889
B01889
B01889
B01889
58
Blower
Z01I033
Z01I035
Z01I036
Z01I038
Z01I038
59
Control board 24V
R99G016
R99G016
R99G016
R99G016
R99G016
60
Control board support
B40559
B40559
B40559
B40559
B40559
61
Transformer 120V-24V
L01F009
L01F009
L01F009
L01F009
L01F009
62
ID blower and PVC elbow ass
N/A
B40766-02
B40766-02
B40766-02
B40766-02
Options
C45-2-V
C60-2-V
C75-2-V
C105-2-V
C120-2-V
Bottom return base assembly
B40691-01
B40691-02
B40691-02
B40691-03
B40691-03
Downflow base
B40632-01
B40632-02
B40632-02
B40632-03
B40632-03
Transition A coil
B40693-01
---
---
---
---
Conversion kit propane
B40574-09
B40574-12
B40574-15
B40574-21
B40574-24
Orifice #56 (LP)
R01I002
R01I002
R01I002
R01I002
R01I002
Replacement kit for drain trap
K01021
K01021
K01021
K01021
K01021
