DeVilbiss COBRA 3C - Model Part Numbers; Specification & Materials of Construction

5 © 2014 Finishing Brands UK Ltd.
Model Part Numbers
CBA3C - ##### - ### N
e.g. CBA3C-590-085N
Where:-
590= 590 Trans-Tech Air Cap
085=0.85mm Fluid Nozzle and Needle
N= Hardened Fluid Nozzle and Needle
e.g. CBA3C-590HV-10N
Where:-
590HV= 590HV HVLP Air Cap
10= 1.0mm Fluid Nozzle and Needle
N= Hardened Fluid Nozzle and Needle
Table 1: Air Cap Range
Air Cap Type
Part No.
Technology
Marking On Cap
590
SP-100-590-K
Trans-Tech
COM 590
590 HV
SP-100-590HV-ADV-K
HVLP
590 HV
Table 2: Hardened Fluid Nozzle and Needle Range
Fluid Nozzle Size
mm
Hardened
Fluid Nozzle
Hardened
Fluid Needle
Marking on
Fluid Needle
0.7
SP-259N-07-K
SPA-353-07-K
3C 07
0.85
SP-259N-085-K
SPA-353-085-K
3C 085
1.0
SP-259N-10-K
SPA-353-10-K
3C 10
Specification & Materials of Construction
Thread
Pressure
Air inlet Pattern + Length (P1)
1
/
8
” BSP Female
P1 Max 12 bar / 174 psi
Fluid inlet & fluid recirculation (P2)
1
/
8
” BSP Female
P2 Max 15 bar / 218 psi
Cylinder/trigger
1
/
8
“ BSP Female
3.5 to 6 bar / 51 to 87 psi
Maximum temperature in use
40° C / 104°F
Spray gun weight
496 g / 17.5 oz.
Materials of construction
Gun body / Manifold / Micrometer Assembly
303 Stainless steel, 6082 Aluminium Alloy
Tip / Needle
Hardened 303 Stainless steel.
Fluid seals
Viton Extreme, Polyethylene, PTFE
Type of
Gun
Air Cap Type
(See Table 1)
Fluid Nozzle Size
(See Table 2)
Hardened
