Devolo dLAN 500 WiFi User Manual

Quick start 17
devolo dLAN 500 WiFi
Begin carrying out the configuration of
your network in order to secure your
Wi-Fi network in a customised manner.
For more information, refer to Chapter
6 Network configuration.
Encrypting a new dLAN network with one or more
dLAN 500 WiFis and a dLAN 500 duo (starter kit
or network kit)
Note the Wi-Fi key of the
dLAN 500 WiFi before the networking
procedure. You will find the unique
adapter key on the label on the back of
the housing.
햲 Connect the dLAN 500 duo to your Internet
access device's network jack.
햳 Plug the dLAN 500 WiFi into a wall socket. As
soon as the indicator light of the dLAN button
lights green (after approx. 45 seconds), the
adapter is ready to operate.
If you only want to use the Wi-Fi func-
tion on the dLAN 500 WiFi, plug the
adapter into a power outlet, without
any cables whatsoever. You can also
connect the dLAN 500 WiFi to the net-
work jack of a network device, such as
a computer, with a commercially avail-
able network cable (see 2.4 Sample ap-
plications).
The power outlet should be in range of
the connected network device.
The dLAN 500 WiFi with the cable-
based network device should be easily
accessible.
To switch off the dLAN 500 WiFi or dis-
connect it from the mains supply, pull
the power plug out of the power out-
let.
햴 After you have successfully connected both adapt-
ers, press first the encryption button of the
dLAN 500 duo (approx. 1second) and then
the dLAN button of the dLAN 500 WiFi (approx.
1second) within two minutes.
햵 That's it! Your dLAN network is now protected
against unauthorised access.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
