Network configuration 75
devolo dLAN 500 WiFi
6.6.4 Update firmware
The firmware of the dLAN 500 WiFi includes the soft-
ware for operating the device. If necessary, devolo of-
fers new versions on the Internet as a file download,
for example, to modify existing functions or to extend
the scope of function.
햲 To bring the firmware up to the latest version, first
go to the devolo website, www.devolo.com
, and
download the appropriate file for the
dLAN 500 WiFi to your computer.
햳 Then in the configuration dialogue, go to the area
Management  Update Firmware. Click
Browse… and select the downloaded file.
햴 Then start the update procedure with the Update
Firmware button. After a successful update, the
dLAN 500 WiFi restarts automatically.
Ensure that the update procedure is
not interrupted. To do so, it is best to
connect your computer to the
dLAN 500 WiFi via dLAN or LAN rather
than Wi-Fi.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
