26 Initial use
devolo dLAN 500 WiFi
4.3.5 Wi-Fi antennas
The internal Wi-Fi antennas are for connecting to other
network devices wirelessly.
4.4 Connecting the dLAN 500 WiFi
This section describes how to connect your
dLAN 500 WiFi to a computer or other network device.
Note the Wi-Fi key of the
dLAN 500 WiFi before the networking
procedure. You will find the unique
adapter key on the label on the back of
the housing.
Use a network cable to connect the
dLAN 500 WiFi to network port of your computer
or other network device.
If you only want to use the Wi-Fi func-
tion on the dLAN 500 WiFi, plug the
adapter into a power outlet, without
any cables whatsoever. (see 2.4 Sample
applications)
Plug the dLAN 500 WiFi into a wall socket. As
soon as the indicator light of the dLAN button
lights green (after approx. 45 seconds), the
adapter is ready to operate.
The power outlet should be in range of
the connected network device.
The dLAN 500 WiFi with the cable-
based network device should be easily
accessible.
To switch off the dLAN 500 WiFi or dis-
connect it from the mains supply, pull
the power plug out of the power out-
let.
A dLAN network is set up as soon as at least one
other dLAN adapter has been connected and
plugged into the mains supply. To secure your
dLAN network individually, continue with your
dLAN network configuration. For more informa-
tion, refer to the chapter 5 dLAN network.
In order to connect the dLAN 500 WiFi via Wi-Fi
with your laptop, tablet or smartphone, enter the
previously noted Wi-Fi key as the network security
key.
If you would like to connect additional adapters,
proceed as just described. For more information,
also read Chapter 3 Quick start.
In order to secure your Wi-Fi network individually,
carry out your network configuration. For more
information, refer to Chapters 5 dLAN network
and 6 Network configuration.

Other manuals for Devolo dLAN 500 WiFi

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Devolo dLAN 500 WiFi and is the answer not in the manual?

Devolo dLAN 500 WiFi Specifications

General IconGeneral
InterfaceEthernet / WLAN
Connectivity technologyWired & Wireless
Ethernet LAN (RJ-45) ports1
SafetyCE B
Chipset-
InternalNo
Product colorWhite
Modulation1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100BaseT(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Security algorithms128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range300 m
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates10, 100 Mbit/s
Maximum data transfer rate500 Mbit/s
Supported network protocolsCSMA/CA
AC input voltage196-250 V
AC input frequency50 Hz
Power consumption (typical)4.4 W
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth41 mm
Width68 mm
Package depth190 mm
Package width115 mm
Package height81 mm
Package weight260 g
