Devolo dLAN 500 WiFi User Manual

70 Network configuration
devolo dLAN 500 WiFi
6.5.7 WiFi Move Technology
Wi-Fi Move Technology is a function for synchronising
the Wi-Fi settings of all dLAN 500 WiFi adapters con-
nected to your home network.
WiFi Move Technology support enabled
햲 Also press the dLAN button of the dLAN 500 WiFi
adapter for which the entire Wi-Fi configura-
tion is to be transferred to all other
dLAN 500 WiFi adapters.
햳 Then tap each dLAN button of the other
dLAN 500 WiFi adapters.
햴 All dLAN 500 WiFi adapters are now continu-
ously connected to each other and, from now
on, share changes to the Wi-Fi configuration
with each other automatically.
Wi-Fi configuration in factory defaults:
In the factory default settings of the
dLAN 500 WiFi, the Wi-Fi function is ena-
bled and the Wi-Fi encryption WPA2 is
configured. The default Wi-Fi key is the
Wi-Fi key of the corresponding device.
You will find the key on the label on
the back of the housing.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
