Devolo dLAN 500 WiFi User Manual

Quick start 19
devolo dLAN 500 WiFi
쎲 The dLAN Cockpit software finds all accessible
dLAN adapters in your dLAN network, displays
information about these devices and encrypts your
dLAN network individually.
쎲 You can configure your Wi-Fi network, along with
other actions, using the configuration inter-
face for your dLAN 500 WiFi.
To install the software, insert the included CD-ROM in
the CD drive of your computer.
If AutoPlay is active on your computer, the in-
stallation will start automatically. Otherwise,
open the directory with the Windows Explor-
er by right-clicking on Start (or the Win-
dows logo) and selecting Explorer from the
context menu. Then start the installation wiz-
ard manually.
You will be asked for permission to transfer anonymous
performance data related to your dLAN adapter to
devolo. The data sent to devolo pertains only to the
performance values of your dLAN devices. The data is
anonymised and will be used exclusively for statistical
purposes. By providing it, you can help us improve our
products. You can find the installed software
applications in the Start  All Programs  devolo
program group.
Software for Mac (OS X)
The software  mac folder contains the dLAN config-
uration software.
Software for Linux (Ubuntu)
The Software  Linux folder contains the dLAN
configuration software.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
