Devolo dLAN 500 WiFi User Manual

dLAN network 37
devolo dLAN 500 WiFi
Before the networking procedure, note
the security IDs of all dLAN adapters.
This unique identifier of each dLAN de-
vice is located on the label on the hous-
ing. It consists of 4 x 4 letters separated
by dashes (e.g. ANJR-KMOR-KSHT-
QRUV). Ensure that all dLAN adapters
are connected to the power grid and
computers or other network compo-
nents as appropriate.
Scan for local adapter
After dLAN Cockpit is started, it searches for the dLAN
adapter connected directly to your computer first.
Adding an adapter
Add all the dLAN devices you want to your dLAN
network by selecting the Add adapter button. You
will need the 16-character security IDs of the adapters
from the label on the housing. Enter it now in the
Security ID field and confirm with OK. If a security ID
is correct and the device can be reached in the dLAN
network, it will be added to your network of configured
adapters and also displayed in the program.
Entering a network password
After you have added all the dLAN devices you want to
your dLAN network, select the Change password
button to assign a shared network password that will
apply for all registered adapters in your personal home
network.
You can choose between your own password, a ran-
dom password and the default password. To define
your own password with a length of at least eight char-
acters, enter this into the Network password text
field. Alternatively, you can have a randomly selected,
highly secure password assigned using the Generate
secure password button. Use the Factory default
password button to reset the dLAN adapter to the de-
fault password. Normally, the display of the password
is hidden for security reasons. If you enable the option
Show characters, the current password is displayed
in legible form in the text field.
The factory default password is
HomePlugAV. Assigning a specific
password to a single adapter will
exclude it from the remaining dLAN
network.
If dLAN Cockpit is called up again later after a suc-
cessful initial installation, for example to integrate a
new adapter into a network, the application remem-
bers the devices that were entered earlier. Enter the
new device as described in the Adding an adapter

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
