Devolo dLAN 500 WiFi User Manual

54 Network configuration
devolo dLAN 500 WiFi
If you would like, you can completely shut off the Wi-Fi
part of your dLAN 500 WiFi, e.g. if you want to operate
it exclusively as a simple dLAN device via the built-in
Ethernet connections. There are three different meth-
ods for switching the Wi-Fi function on and off:
쎲 Press the ON/OFF button on the front panel of
the device. Detailed information on switching the
device on and off can be found in Chapter 4.3.1
Wi-Fi button.
쎲 Use the Enable WLAN or Disable WLAN button
on the configuration interface under WLAN con-
figuration.
쎲 Enable the Wi-Fi time control. For more informa-
tion, refer to Chapter 6.5.5 WLAN time con-
trol.
The operating state of the device is displayed
under 6.3 Status overview.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
