62 Network configuration
devolo dLAN 500 WiFi
The Wi-Fi filter should be used only as
an additional option. By using it you
could limit access to your wireless net-
work, but without encryption it would
be relatively easy for third parties to
eavesdrop on all of your data transmis-
sions.
To use the Wi-Fi filter, enable the option Enable fil-
ters. Now you can manually enter different network
devices to provide access to your dLAN 500 WiFi using
what is known as their MAC address or you can select
take them from a list of known devices (see 6.3.2
WLAN status  WLAN monitor). Confirm each entry
with Add.
Approved Wi-Fi stations
Network devices or stations connected to your
dLAN 500 WiFi are automatically listed, that is, to en-
able an already connected station for the
dLAN 500 WiFi, simply select the MAC address of the
respective device and confirm it with Add. This then
appears under Approved WLAN stations. To remove
an enabled station, select its MAC address and confirm
it with Delete selected.
The Wi-Fi filter can only be set for sta-
tions connected directly to the access
point (not the guest account).
The MAC address designates the hardware
interface of each individual network device
uniquely (e.g. the Wi-Fi adapter of a comput-
er or the Ethernet port of a printer). It consists
of six double-digit hexadecimal numbers,
each separated by a colon (e.g.
00:0B:3B:37:9D:C4).
You can easily determine the MAC address of a Win-
dows computer by opening the window with the com-
mand prompt under Start  All Programs 
Accessories  Command Prompt. Enter the com-
mand IPCONFIG /ALL here. The MAC address is dis-
played under the designation Physical address.
After entering the MAC addresses, do not forget to
click the Save button. If the entered values are incor-
rect (e.g. because the colons are missing), a corre-
sponding error message is displayed.
Keep in mind that you also have to en-
ter the MAC address of your own com-
puter if you are connected to the
dLAN 500 WiFi not via the Ethernet
port, but via Wi-Fi. Otherwise you will
block your own access to the device
via Wi-Fi by activating the Wi-Fi filter!

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
