Devolo Magic2 LAN DINrail User Manual

Introduction 14
devolo Magic 2 LANDINrail
PLC (Fig. 2)
PLC-LED Flashing be-
haviour
Meaning LED status display
(web interface*)
1 Red LED Lights up for
up to 2 sec.
Start-up process Cannot be disabled
2 Red LED Flashes at in-
tervals of 0.5
sec. (on/off)
Status 1:
The reset of the devolo Magic adapter was
successful. The reset button has been pres-
sed and held for 10 seconds.
Status 2:
The devolo Magic adapter (once again) has
the factory default settings. Since the last re-
set, no pairing with another devolo Magic
adapter has taken place.
Connect the adapter with another
devolo Magic adapter to create a full-
fledged PLC network as described in Chap-
ter 4 Initial use.
Cannot be disabled

Devolo Magic2 LAN DINrail Specifications

General

Product Type	Powerline adapter
Maximum Data Transfer Rate	2400 Mbps
Operating Temperature	0°C to 40°C
Mounting	DIN rail
Encryption	128-bit AES
Frequency Range	2-86 MHz
Operating Frequency	50/60 Hz
Device Type	Powerline
Operating Voltage	100-240 V
Storage Temperature	-25°C to 70°C
Humidity	10-90% non-condensing
Certifications	CE, RoHS
Standards	HomePlug AV2, IEEE 1901
