Elektrical installation 22
devolo Magic 2 LANDINrail
a liquid has been spilled on the device or
objects have fallen into the device.
a the device has been exposed to rain or
water.
a the device does not work, even though the
operating instructions have been followed
properly.
a the device’s case is damaged.
3.4 Installation
1 Install the devolo Magic 2 LAN DINrail properly
on the top-hat rail.
Take into account the vertical installation
alignment of the device, so that the mains
power supply comes from above.
2 Now connect the conductors according to the
line connections.
When connecting to the sockets, make sure
the conductor cross-section is 0.18 mm² to 6
mm².
DANGER! Risk of fire caused by incorrect
conductor cross-section and improper in-
stallation of the power supply
Comply with the specified conductor cross-
sections and ensure the power supply is
correctly installed
a Single-phase connection: Neutral conduc-
tors and external conductors are connected
to terminals N and L1 (see Fig. 3).
a Three-phase connection: Neutral conduc-
tors and three external conductors are
connected to terminals N, L1, L2 and L3.
The device is supplied with power via ter-
minals N and L1 (see Fig. 4).
a PE connection: The earth wire must be
connected to the PE terminal.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Devolo Magic2 LAN DINrail and is the answer not in the manual?

Devolo Magic2 LAN DINrail Specifications

General IconGeneral
Product TypePowerline adapter
Maximum Data Transfer Rate2400 Mbps
Operating Temperature0°C to 40°C
MountingDIN rail
Encryption128-bit AES
Frequency Range2-86 MHz
Operating Frequency50/60 Hz
Device TypePowerline
Operating Voltage100-240 V
Storage Temperature-25°C to 70°C
Humidity10-90% non-condensing
CertificationsCE, RoHS
StandardsHomePlug AV2, IEEE 1901
