Devolo Magic2 LAN DINrail User Manual

Introduction 16
devolo Magic 2 LANDINrail
5White
LED
Status 1:
Flashes at in-
tervals of
0.5 sec.
(on/off)
Status 2:
Flashes at in-
tervals of
1 sec.
(on/off)
Status 1:
This devolo Magic adapter is in pairing
mode and the system is searching for new
devolo Magic adapters.
Status 2:
Someone has triggered the "Identify device"
function on the web interface or in the
devolo Home Netwok App. This function
identifies the devolo Magic adapter being
sought.
Cannot be disabled
6White
LED
Lights up stea-
dy
The devolo Magic connection does not have
any issues and the devolo Magic adapter is
ready to operate.
Can be disabled
7White
LED
Flashes at in-
tervals of
0.25 sec. on/
3sec.off
The devolo Magic adapter is in standby mo-
de.**
Can be disabled
8Red and
white
LED
Flashes at in-
tervals of
0.3 sec. red/
0.3 sec. white
The devolo Magic adapter is carrying out a
firmware update.
Cannot be disabled
PLC-LED Flashing be-
haviour
Meaning LED status display
(web interface*)

Devolo Magic2 LAN DINrail Specifications

General

Product Type	Powerline adapter
Maximum Data Transfer Rate	2400 Mbps
Operating Temperature	0°C to 40°C
Mounting	DIN rail
Encryption	128-bit AES
Frequency Range	2-86 MHz
Operating Frequency	50/60 Hz
Device Type	Powerline
Operating Voltage	100-240 V
Storage Temperature	-25°C to 70°C
Humidity	10-90% non-condensing
Certifications	CE, RoHS
Standards	HomePlug AV2, IEEE 1901
