Attaching the Auxiliary Handle (Fig.B)

WARNING: This handle SHOULD BE USED AT ALL
TIMES to maintain complete control of the tool. Always
make sure the handle istight.
Screw the auxiliary handle
6
tightly into one of the
threaded mounting holes
25
of the gearcase.
Rotating the Gear Case (Fig.C)
To improve user comfort, the gear case will rotate 90° for
cuttingoperations.
1. Remove the four corner screws (T25) attaching the gear
case to motorhousing.
2. Without separating the gear case from motor housing,
rotate the gear case head to desiredposition.
NOTE: If the gear case and motor housing become
separated by more than 1/8" (3 mm), the tool must be
serviced and reassembled by a DeWALT service center.
Failure to have the tool serviced may lead to motor and
bearingfailure.
3. Reinstall screws to attach the gear case to the motor
housing. Tighten screws to 28 in‑lbs. torque. Overtightening
could cause screws tostrip.
Guards

CAUTION: Guards must be used with all grinding
wheels, cutting wheels, sanding flap discs, wire brushes,
and wire wheels. The tool may be used without a guard
only when sanding with conventional sanding discs. Refer
to Figure A to see guards provided with the unit. Some
applications may require purchasing the correct guard from
your local dealer or authorized servicecenter.
NOTE: Edge grinding can be performed with Type
27wheels designed and specified for this purpose; 1/4"
(6.35 mm) thick wheels are designed for surface grinding.
A Type1/41 / TypeA guard must be used for any wheel
where surface grinding is forbidden. Cutting can also be
performed by using a Type1/41 wheel and a Type1/41 /
TypeAguard.
NOTE: See the Accessories Chart to select the proper
guard/accessorycombination.
Flanges and Wheels

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.
Mounting Non‑Hubbed Wheels (Fig.A, E)

WARNING: Failure to properly seat the flanges and/or
wheel could result in serious injury (or damage to the tool
orwheel).

CAUTION: Included flanges must be used with depressed
center Type 27/42 grinding wheels and Type1/41 cutting
wheels. See the Accessories Chart for moreinformation.

WARNING: A closed, two‑sided cutting wheel guard is
required when using abrasive cutting wheels or diamond
coated cutting wheels.

WARNING: Use of a damaged flange or guard or failure
to use proper flange and guard can re sult in injury due to
wheel breakage and wheel contact. See the Accessories
Chart for moreinformation.
Adjusting and Mounting Guard(Fig.A, D)

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack before
making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.

CAUTION: BEFORE operating the tool, identify which
guard adjustment option your tool is setto.
Adjustment Options
For guard
9
adjustment, the guard release lever
10
engages one of the alignment holes
14
on the guard collar
using a ratchetingfeature.
• One-touch
TM
: In this position the engaging face is slanted
and will ride over to the next alignment hole
14
when
guard is rotated in a clockwise direction (spindle facing user)
but self‑locks in the counterclockwisedirection.
Mounting Guard

CAUTION: Prior to mounting guard, ensure the screw,
lever, and spring are fitted correctly before mounting
theguard.
1. With the spindle facing the operator, press and hold the
guard release lever
10
.
2. Align the lugs
15
on the guard with the slots
16
on the
gearcasecover.
3. Push the guard down until the guard lugs engage and
rotate them in the groove on the gear case cover. Release
the guard releaselever.
4. To position the One‑touch
TM
guard : Rotate the guard
clockwise into the desired working position. Press and
hold the guard release lever
10
to rotate the guard in the
anti‑clockwisedirection.
NOTE: The guard body should be positioned between
the spindle and the operator to provide maximum
operatorprotection.
The guard release lever should snap into one of the
alignment holes
14
on the guard collar. This ensures that
the guard issecure.
5. To remove the guard, follow steps 1–3 of these
instructions inreverse.
shut the grinder off. The switch will need to cycled off and
then back on to restarttool.
Power‑OFF™ Overload Protection
The power supply to the motor will be reduced in case
of motor overload. With continued motor overload, the
tool will shut off. The switch will need to cycled off and
then back on to restarttool. The tool will power off each
time the current load reaches the overload current value
(motor burn‑up point). If continued overload shutdowns
occur, apply less force/weight on the tool until the tool will
function without the overloadengaging.
Electronic Soft Start
This feature limits the initial start up momentum, allowing
the speed to build up gradually over a 1secondperiod.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.
