DeWalt DWE4997 Instructions

25
ENGLISH
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Visible radiation. Do not stare into light.
Package Contents
The package contains:
1 Die grinder
1 Wrench
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Features
No-volt Protection
The ON/OFFswitch has a no-volt release function. In the event of
a power outage or other unexpected shut down, the switch will
need to be cycled (turned on and off) to restarttool.
E-Clutch
This unit is equipped with an E-Clutch (Electronic Clutch), which
in the event of a stall or wheel pinch, the unit will be shut off to
reduce the reaction torque to the user. The switch needs to be
cycled (turned on and off) to restarttool.
Brake
When the trigger switch is released the motor immediately
turns off and electronically brakes, stopping the accessory
quickly to prevent accidental contact and improveproductivity.
Constant Clutch
When overloaded or stalled the motor torque is reduced to
allow the user to maintain control of the tool. If load is reduced
the torque and RPM will increase. If the tool is stalled for an
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Spindle
2
Spindle lock button
3
Collet nut
4
Small spanner (13mm)
5
Large spanner (17mm)
6
Collet 6mm
7
LED worklight
8
Slider switch
9
Variable Speed Dial
10
LED indicator
Intended Use
Your die grinder has been designed for professional grinding
applications. The tool can be used with the complete range of
commerical grinding accessories with a maximum diameter of
50mm and approved minimum speed of 25000/min.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This die grinder is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the rating plate.
Your
DeWALT
tool is double insulated in accordance
with EN62841; therefore no earth wire is required.
If the supply cord is damaged, it must be replaced only by
DeWALT
or an authorised serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.

WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5 mm
2
; the
maximum length is 30 m.
When using a cable reel, always unwind the cablecompletely.
Date Code Position (Fig. A)
The date code
13
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
