• Equipareaofoperationwitha
fire extinguisher.
• Donotoperatemachinewith
missing, broken, or un au tho-
rized parts.
• Neverstandonthecompressor
WARNING: RISK OF FALLING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Aportablecompressor
can fall from a table,
workbench, or roof causing
damage to the compressor
and could result in serious
injuryordeathtothe
operator.
• Alwaysoperatecompressor
in a stable secure position to
prevent accidental movement
of the unit. Never operate
compressor on a roof or
other elevated position. Use
additional air hose to reach
high locations.
CAUTION: RISK FROM NOISE
WHAT CAN HAPPEN HOW TO PREVENT IT
Pump/Motor Specifications
Maintenance free universal motor
Voltage: Single 120V
Minimum branch circuit requirement: 15 A
Fuse Type: Time delay
Specifications
MODEL
DWFP55120
AIR TANK CAPACITY
3 gallons (11.4 liters)
APPROX CUT-IN PRESSURE
105 psi
APPROX. CUT-OUT PRESSURE
135 psi
SCFM @ 90 PSI
1.8
A. On(I)/Off(O) Switch
B. Tank Pressure Gauge
C. Outlet Pressure Gauge
D. Regulator
DWFP55120 Air Compressor
E. Safety Valve
F. Drain Valve
G. Check Valve
H. Air Outlet (1/4” NPTF)
