Connectors
Typical DEWE-5000 rear view
Typical DEWE-5000 side view
Typical DEWE-5000 front view
Note: The location of the connectors might vary from system to system and depends on system
conguration
Connector overview:
1. Power supply connector with
general power switch
2. PS/2 keyboard connector
3. PS/2 mouse connector
4. USB interface connectors
5. LPT interface connector
6. 2x RS-232 interface connectors
7. VGA connector
8. Ethernet LAN connector
9. Power-on button
10. Ground connectors
11. Digital I/O connector
12. Combustion Analyzer connectors
(DEWE-5000-CA only)
Combustion Analyzer option
