8514-296-001 REV A page 37
When manual programming mode is entered, the “Start”, “Hot”, “Warm” and “Cold”
buttons perform alternate functions.
Button Name Alternate Function in Programming Mode
Start
Becomes the action to accept the displayed option or
the “Enter” key
Hot
Becomes the action to move UP through displayed
options (Press & hold for accelerated scrolling)
Warm
Becomes the action to move DOWN through displayed
options (Press & hold for accelerated scrolling)
Cold
Becomes the action to move back a step (1 press) or
EXIT from programming mode (press for 3 seconds)
These alternate functions allow the user to move through a menu of options to choose
various programmable settings. The figure below shows the top level menu. Choosing
an option from the top level menu will then display the next level of options (the sub
menu).
