8514-296-001 REV K page 1
COMMERCIAL WASHERS
MODELS T-300/350/400/450/600/650/750/900/950/1200/1450/1800
VENDED C-SERIES CONTROL
OPERATOR’S MANUAL
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING UNLESS
QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should NOT be allowed to operate if any of the following occur:
- Excessively high water level.
- If machine is not connected to a properly grounded circuit.
- If the door does not remain securely locked during the entire cycle.
- Vibration or shaking from an inadequate mounting or foundation.
WARNING - SAFETY PRECAUTIONS
- Always shut off power and water supply before servicing.
- Do not overload the washer.
- Do not open door when cylinder is in motion or it contains water.
- Do not bypass any safety devices of this washer.
- Do not use volatile or flammable substances in or near this washer.
- Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
PREVENTIVE MAINTENANCE REQUIREMENTS
DAILY
- Check that the loading door remains securely locked and cannot be opened during an entire
cycle.
- Clean the top, front, and sides of the cabinet to remove residue.
- Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and
tight.
- Check the loading door for leaks. Clean the door seal of all foreign matter.
- Leave the loading door open to aerate the washer when not in use.
QUARTERLY
- Make sure the washer is inoperative by switching off the main power supply.
- Check the V-belts for wear and proper tension.
- Clean lint and other foreign matter from around motor.
- Check all water connections for leaks.
- Check the drain valve for leaking and that it opens properly.
- Wipe and clean the inside of the washer and check that all electrical components are free of
moisture and dust.
- Remove and clean water inlet hose filters. Replace if necessary.
- Check anchor bolts. Retighten if necessary.
IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly
maintenance.

Table of Contents

Other manuals for Dexter Laundry A Series

Preview: Parts & Service Manual
Parts & Service Manual77 pages
Preview: Operator's Manual
Operator's Manual68 pages
Preview: Service Procedures And Parts Data
Service Procedures And Parts Data110 pages

Questions and Answers

  • B
    barry02Sep 7, 2025
    What to do if cold water does not enter the tub in wash cycle of my Dexter Laundry A Series?
    • P
      pwallsSep 7, 2025
      If cold water isn't entering the tub during the wash cycle of your Dexter Laundry Washer, start by checking the water valve coil for continuity at the terminals and replace it if there's no continuity. Also, check for 24 VAC (50 Hz) power from the main relay PCB. Inspect the water inlet screens for blockage and clean them if necessary. Ensure that the water supply is turned on and operating correctly. Finally, check the black and white wire at the Molex plug on the main PCB controller P21 connection and at the PCB relay board P20 connection, and examine the pressure switch continuity between terminal contacts. If no continuity, check the pressure switch hose for obstruction. If the hose is okay then change the pressure switch.
