18
8514-300-001 REV PR
SWD Vended Washers
T-350 STACK WASHER-DRYER
UNIT
T-450 STACK WASHER-DRYER
UNIT
Capacity
Dry Weight Capacity Per Machine - lb (kg)
20 (9.1) 30 (13.6)
Washer Cylinder Volume - cu ft (L)
2.7 (76.5) 4 (113.3)
Speed
Washer High Extract Speed - g (RPM)
200 (819) 200 (750)
Washer Intermediate Extract Speed - g (RPM)
60 (449) 60 (411)
Washer Washing Speed - g (RPM)
0.9 (55) 0.9 (50)
Washer Motor Size - hp (kW)
1 (0.75) 2 (1.5)
Dimensions
Overall Cabinet Height - in (cm)
74 3/4 (189.9) 78 3/8 (199)
Overall Cabinet Width - in (cm)
27 (68.6) 31 1/2 (80)
Overall Cabinet Depth - in (cm)
44 5/8 (113.7) 49 7/16 (125.6)
Washer Cylinder Diameter - in (cm)
21 (53.3) 25 (63.5)
Washer Cylinder Depth - in (cm)
13 1/2 (34.3) 14 1/8 (35.9)
Washer Door Opening - in (cm)
12 1/4 (31.1) 15 1/4 (38.7)
Floor to Washer Door Bottom - in (cm)
14 7/8 (37.8) 12 7/16 (31.6)
Weight
Net Weight - lb (kg)
800 (362.9) 1051 (476.7)
Shipping
Shipping Weight - lb (kg)
840 (381) 1101 (499.4)
Shipping Height - in (cm)
80 5/8 (204.8) 84 (213.4)
Shipping Width - in (cm)
29 1/4 (74.3) 34 (86.4)
Shipping Depth - in (cm)
49 3/4 (126.4) 54 (137.2)
Installation
Min. Clearance Between Machines - in (cm)
1/2 (1.3) 1/2 (1.3)
Min. Clearance Behind Machines - in (cm)
24 (61) 24 (61)
Min. Concrete Thickness - in (cm)
6 (15.2) 6 (15.2)
Water
Water Inlet Size - in (mm)
3/4 (19) 3/4 (19)
Pressure (min-max) - psi (kPa)
30-120 (207-827) 30-120 (207-827)
Flow Rate - gal/min (L/min)
9 (34) 9 (34)
Approx. Water Usage Per Cycle - gal (L)
15.8 (59.8) 23.5 (89)
Drain Diameter (O.D.) - in (cm)
2 1/4 (5.7) 3 (7.6)
Floor to Center of Drain - in (cm)
5 7/8 (14.9) 4 7/16 (11.3)
Electrical Model
Volts / Hz / Phase / Wiring/Distribution
System Circuit Breaker Amps / Running Amps / Wire Size/ Reversing Capability
-59
230 / 50 / 1 / 2 wire + ground / TN-S 15 / 6.2 / 3.5 mm² 15 / 6.5 / 3.5 mm²
Table 6-3 SWD Vended Washer Specificaons
