72
8514-300-001 REV PR
When manual programming mode is entered, the “Start”, “Hot”, “Warm” and “Cold” buttons
perform alternate functions.
Button Name Alternate Function in Programming Mode
Start
Becomes the action to accept the displayed option or the
“Enter” key
Hot
Becomes the action to move UP through displayed options
(Press & hold for accelerated scrolling)
Warm
Becomes the action to move DOWN through displayed
options (Press & hold for accelerated scrolling)
Cold
Becomes the action to move back a step (1 press) or EXIT
from programming mode (press for 3 seconds)
Table 7-3 Buons Alternate Funcons in Programming Mode
These alternate functions allow the user to move through a menu of options to choose various
programmable settings.
Figure 7-43 Programming Menu Opons
