91
8514-300-001 REV PR
Acon
Stop the machine and clear the cycle. Keep the
door locked unl the machine has stopped
moving and then unlock the door.
Soluon
Check the data communicaon cable between
the washer computer and the variable
frequency drive (VFD).
Step 1: Make sure the cable did not become
unplugged during operaon. Step 2: Make
sure that the cable is not being pulled
sideways at either the washer controller, or
the VFD, plug end. If both ends of the
communicaons cable are plugged in the
washer computer and VFD and there is no
tension on the communicaons cable pulling it
from side to side, then replace the cable. Step
3: Inspect both female connecon points at
PCB controller and at VFD. These may need
replacement if they cannot be reset.
COMM ERROR5
VFD
Communicaon
Fault
Condion
This error is caused when the control detects
no cylinder moon when it should be rotang.
Delay Immediate
Acon
The washer cycle will connue but without any
cylinder moon. “COMM_ERROR_5” will flash
three mes then wait 30 seconds and then
repeat. No change in operaon.
Soluon
Check the VF drive enable wire connecons
from relay board to drive.
SLOW DRAIN ERROR Drain Error Condion
This error is when an empty water level is not
reach within 7 minutes.
Delay Immediate
Acon
The washer cycle will connue. Do not spin the
tumbler without reaching an empty water
level. If empty water level is not reached,
agitate during the normal spin me.
Soluon
Check VFD fault light before turning off power.
Check to ensure the drain valve is operang
properly (slow drain has potenal to cause this
code). Check to ensure the pressure switch
tube is clear of any blockage, and the pressure
switch is operang properly. Check the
pressure switch harness.
SPIN STOP ERROR Stop Error Condion
This error is when the washer does not stop
spinning within 150 seconds aer receiving the
command.
Delay Immediate
Acon
Keep the door locked unl the machine has
stopped moving and then unlock the door.
To Next Page
