Dexter Laundry A Series Operator's Manual

8514-296-001 REV A page 65
board.
Black or white wire at
controller and main relay
PCB
Check black and white wire at Molex plug on main PCB controller
P21 connection and at PCB relay board P20 connection.
Water does
not flush
softener
compartment.
Water Valve Coil Check coil continuity at terminals and replace if no continuity.
Water Inlet Screens Check water inlet screens for blockage and clean if necessary.
Water Check to ensure that water is turned on and operating.
Pressure Switch
Check pressure switch continuity between terminal contacts. If no
continuity, check pressure switch hose for obstruction. If the hose is
okay then change pressure switch.
Water level
too high
Pressure Switch
Check for blockage in pressure switch hose. Check for pressure
switch opening circuit across terminals. Replace switch if contacts do
not open.
Water drains
slowly
Drain System
Check hoses and drain valve for blockage. Check to make sure
building drain is of adequate size. Check building drains for
blockage.
Machine does
not turn
VFD
Check VFD by removing top panel. If no display turn power off to
machine at breaker for 2 minutes and turn power back on to reset.
If still no display replace VFD.
Machine
tumbles in
one direction
VFD See DISPLAYED WASHER FAULTS section for more info.
VFD Inspect yellow enable wires from main relay PCB and at VFD
Excessive
vibration
Mounting System
Check these areas:
• Strength of mounting structure, concrete or base.
• Mounting bolts may be loose and need tightening.
Drive Belt Worn drive belt can cause vibration and noise.
Loading
Small loads contribute to out of balance loading and increase
vibration.
Machine does
not spin
Pressure Switch
Check pressure switch for continuity across terminals #21 & #22
indicating pressure switch has reset to the empty position. If no
continuity, change pressure switch.
Machine
starts and
does not
operate
VFD
Check yellow enable wires from PCB relay board connection P13 &
P14 to the VFD. Check connection of orange wire at P15 from door
switches.
Machine does
not stop
Main PCB Main PCB controls time of the cycle and the end of cycle.
Braking Resistors
Check braking resistors for continuity. Verify ohms resistance at
braking resistors with wires removed.
