8514-219-001 REV E PAGE 21
TEMPORARY DRYER CONTROLLER PROGRAMMING EXAMPLE
REQUIREMENTS: Dry a load with 40 minutes of actual heat at 185
0
F and five minutes of
cool down.
The following procedure will show you how to temporarily modify the existing dry cycle 1
program for one cycle of drying. It is based on the assumption that the factory defaults have
not been permanently changed. If they have been changed, the steps of this procedure will
be the same, but the values that are displayed will be different. The amount of times that the
UP or DOWN touch pad switch on the dryer controller must be pressed and released may
also be different.
If you want the change to be permanent, go to the “PERMANENT DRYER CONTROLLER
PROGRAMMING” section of this manual.
PROCEDURE
1) After the load has been placed in the dryer, press and release either the UP or DOWN
touch pad switch on the dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2) Press and release the CYCLE touch pad switch on the dryer controller. You will see the
number “35” on the dryer controller display. The programming L.E.D. and dry time L.E.D.
will be illuminated.
3) Press and release the UP touch pad switch on the dryer controller 10 times so the display
will show a flashing “45”. When the UP touch pad switch is pressed the first time, the
number “36” will be flashing on the dryer controller display. Each number after that will
also flash.
4) Now, press and release the SELECT/ENTER touch pad switch on the dryer controller. The
number “45” will stop flashing and the dry time L.E.D. will switch off. The dryer controller
display will now show “180”, the temperature L.E.D. will illuminate, and the programming
L.E.D. and dry cycle 1 L.E.D. will remain on.
5) Press and release the UP touch pad switch on the dryer controller 1 time so the controller
display will show a flashing “185”. Each press of the UP touch pad switch will increment
the temperature by five degrees.
6) Now, press and release the SELECT/ENTER touch pad switch on the dryer controller.
The number “185” will stop flashing and the temperature L.E.D. will switch off, the dryer
control display will show a number “5”, the cool down L.E.D. will illuminate, and the
programming L.E.D. and dry cycle 1 L.E.D. will remain on.
7) Press and release the SELECT/ENTER touch pad switch on the dryer controller, since the
desired cool down time is five minutes. After you press the SELECT/ENTER touch pad
switch on the controller, the cool down L.E.D. and programming L.E.D. will switch off, the
controller display will remain at “5” and the cycle 1 L.E.D. will remain on.
You are now ready to start the new dry cycle. This new dry cycle will be in effect for one
dry cycle only. After the dry cycle is done, or if the STOP touch pad switch on the dryer
