54
8514-311-001 REV PR
9. Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once
the SELECT/ENTER touch pad switch is pressed and released, the temperature L.E.D.
will switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, the cool
down L.E.D. will illuminate, and the cool down time will be shown on the 4-digit numeric
display.
10. Press and release either the UP or DOWN touch pad switch on the dryer controller to
change the cool down time. Once either the UP or DOWN touch pad switch is pressed,
the cool down L.E.D. and the cool down time on the 4-digit numeric display will flash. If
you press and hold down either the UP or DOWN touch pad switch, you will increment
(UP arrow) or decrement (DOWN arrow) through the cool down times available (2
through 60 minutes if the controller has a red dot sticker or 2 through 15 minutes if the
controller has no red dot sticker, If 170 degrees or higher 4 minute minimum). To not
change the cool down time, do not press either the UP or DOWN touch pad switch. Go
to the next step.
11. Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the
SELECT/ENTER touch pad switch is pressed and released, the cool down L.E.D. will
switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, and the 4-digit
numeric display will change to “Prog”.
12. Press and release the STOP touch pad switch on the dryer controller to save the cycle
program and escape the programming mode. If you want to change the same dry cycle
program again, press the SELECT/ENTER touch pad switch and continue at step 6 of
this procedure. If you want to modify another dry cycle program, go to step 4 of this
procedure and continue.
13. If you pressed the STOP touch pad switch to escape the programming mode, you may
now start the dry cycle by pressing the START touch pad switch.
7.4.5.1 Permanent Dryer Controller Programming Procedure Example
REQUIREMENTS: Dry a load with 50 minutes of actual heat at 195°F and 4 minutes of cool
down.
The following procedure will show you how to permanently modify the existing dry cycle 1
program for one cycle of drying. It is based on the assumption that the factory defaults have
not been permanently change. If they have been changed, the steps of this procedure will be
the same, but the values that are displayed will be different. The amount of times that either
the UP or DOWN touch pad switch of the dryer controller must be pressed and released may
also be different.
If you want the change to be temporary (for only one dry cycle), go to section 7.4.3 Temporary
Dryer Controller Programming.
Procedure:
1. After the load has been placed in the dryer, press and release either the UP or DOWN
touch pad switch on the dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2. Press and release the PROG touch pad switch on the dryer controller. The display of
the dryer controller will not change.
