8514-265-001 REV C PAGE 24
During the dry cycle, either pressing the STOP touch pad key on the dryer controller or opening the dryer
loading door, will stop the dry cycle and not clear it. If you press the STOP touch pad key on the controller
and then open the dryer loading door the dry cycle will not be cleared. However, if you open (or open and
close) the dryer loading door and then press the STOP touch pad key on the dryer controller, the present dry
cycle will be cleared and the word “LOAd” will appear on the dryer controller display.
IMPORTANT: Clothes should be removed from the dryer as soon as possible after the cycle is completed and then
folded or hung to prevent excessive wrinkling.
AVERTISSEMENT. Pour réduire les risques d’incendie, de choc électrique et de blessure, lire les IMPORTANTES
MESURES DE SÉCURITÉ avant d’utiliser cet appareil.
There are two jumpers and one push button on the component side of the dryer controller printed circuit
board.
The jumper located at the back right side of the each circuit board controls whether the controller display
shows and operates in the Fahrenheit or Celsius mode. This jumper is labeled as TEMP SELECT and has
three pins. The back and middle pins are for Celsius and the front and middle pins are for Fahrenheit, which
is indicated by the letter C for Celsius and the letter F for Fahrenheit.
The other jumper, located at the back middle side of each circuit board controls, is used for choosing either a
reversing or non-reversing type of dryer. This jumper is labeled as REV and NON-REV. This jumper must be
in the non-reversing position, which are the front and middle pins. If the jumper is in the reversing position,
the heating part of the dry cycle will not operate properly. The dryer will not reverse direction either.
The push button, which is located at the middle center of each circuit board controls, is used to reset all five
of the dry cycles to the factory default settings. It is labeled as DEFAULT SETTINGS. Even the dry cycles
that have been modified using the permanent programming procedure will be changed back to the factory
default settings when using this push button. This push button must be pressed and held for at least three
seconds with power applied to the dryer controller circuit board.
If changing a jumper, remove power before moving jumper and then move jumper. Before restoring power,
press and hold the DEFAULT SETTINGS pushbutton. Then, restore power and release the DEFAULT
SETTINGS pushbutton after three seconds of restoring power.
TEMPORARY DRYER CONTROLLER PROGRAMMING
The temporary programming mode will allow the change of the stored dry cycle settings in the dryer controller
for one complete dry cycle. After the dry cycle is complete, the default settings that existed before the temporary
change are restored. The temporary dry cycle can be stopped and cleared at any time during the dry cycle
operation.
To temporarily change a dryer controller cycle, follow the procedures below. Things that are displayed on the
4-digit numeric display will be in “quotation marks”. Keys on the dryer controller touch pad that physically need
to be pressed will be in CAPITAL AND BOLD LETTERS.
If, at any time, you want to escape the temporary programming mode while changing the program settings,
you can press the STOP key on the dryer controller touch pad if the 4-digit numeric display is not flashing. The
SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter the flashing value
shown on the 4-digit numeric display and allow you to escape.
If you press and release the STOP key on the dryer controller touch pad, when the 4-digit numeric display is
not flashing, the temporary changes to the dry cycle program will be cancelled. The stored dry cycle settings that
existed before the temporary change will then be restored.
If, at any time, you want to start the temporary dry cycle during the temporary programming mode, press and
release the START key on the dryer controller touch pad if the 4-digit numeric display is not flashing. The
SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter the flashing value
