Dexter Laundry B Series - Dryer Fault Codes

8514-265-001 REV C PAGE 19
DRYER CONTROLLER FACTORY DEFAULT PROGRAM SETTINGS
DRY
CYCLE
COOL DOWN
TIME
(MINUTES)
TOTAL CYCLE
TIME
(MINUTES)
DRYING
TEMPERATURE
(
0
F) (
0
C)
DRYER LOAD
1 5 35 180 82 Towels, pads, heavy cotton
2 2 20 170 77 Sheets, blended materials
3 5 25 180 82 Cotton
4 2 20 130 54 Synthetic materials
5
2
25
175
79
Blended materials
DRYER FAULT CODES
FAULT
#
FAULT
DESCRIPTION
ACTION
F1
Shorted
thermostat
sensor.
Dryer stops and “F1” flashes on the 4-digit display.
When short circuit on sensor input is removed, “LOAd”
appears on the 4-digit display and the remaining dry
time is reset.
F2
Open thermostat
sensor.
Dryer stops and “F2” flashes on the 4-digit display.
When a good sensor is connected to sensor input,
“LOAd” appears on the 4-digit display and the remaining
dry time is reset.
F3
EEPROM
corrupted.
Dryer will not start and “F3” appears on the 4-digit
display. The power to the dryer must be cycled to reset
the controller. Fault should only occur when starting a
dry cycle.
F4
Heating element
on fault.
The drying temperature did not increase 1
º
F. in 15
minutes. “F4” will flash on the display and the dry cycle
will finish without calling for heat (energizing element
contactor). Opening the door or pressing the STOP key
will reset the fault and clear the remaining time in the
dry cycle.
F5
Temperature
fault.
The drying temperature is at least 25
º
F. above the
temperature setting. “F5” will flash on the 4-digit display
and the dry cycle will finish without calling for heat
(energizing the element contactor). The power to the
dryer must be cycled to reset the controller.
