8514-265-001 REV C PAGE 3
SPECIFICATIONS
20 lb. (9.1kg) Industrial Dryer: T-20X2
DN20X2E_-(82/84/85/86/87)_B_
Cabinet Height 68 1/2” 1740 mm.
(Assumes minimum leveling leg adjustment)
Cabinet Width 27” 686 mm.
Cabinet Depth 44 5/8” 1133 mm.
Floor to Bottom of Door- Bottom Dryer 8 1/2” 216 mm.
Floor to Bottom of Door- Top Dryer 42” 1067 mm.
Door Opening 18 1/8” 460 mm.
Dry Wt. Capacity 20 x 2 lbs. 9.1 x 2 kg.
Cylinder Diameter 25 1/2” 648 mm.
Cylinder Depth 24” 610 mm.
Cylinder Volume 7.0 cu. ft. 198 liters
Lint Screen Area 285 sq. in. 1839 sq. cm.
Exhaust Size 8” 203 mm.
Make-up Air 1.0 sq. ft. 929 sq. cm.
Example: 1.0 sq. ft = 1 ft. long X 1 ft. wide
Motor Size (per dryer) 1/3 H.P. .248 kW
Airflow (per dryer - 50 hz) 300 CFM 8.5 m^3/min
Electrical Specifications – Model -82
Voltage/Hz/Phase 400V/50Hz/3Phase/15kW Heat
Running Amps 30 Amps
Minimum Dual Element Time Delay Fuse 30 Amp
Wire Size 8.5 mm^2
Electrical Service 4 wire + ground
Electrical Specifications – Model -84
Voltage/Hz/Phase 208V/60Hz/3Phase/15kW Heat
Running Amps 55 Amps
Minimum Dual Element Time Delay Fuse 60 Amp
Wire Size #4
Electrical Service 4 wire + ground
Electrical Specifications – Model -85
Voltage/Hz/Phase 240V/60Hz/3Phase/15kW Heat
Running Amps 50 Amps
Minimum Dual Element Time Delay Fuse 50 Amp
Wire Size #4
Electrical Service 4 wire + ground
Electrical Specifications – Model -86
Voltage/Hz/Phase 208V/60Hz/1Phase/16kW Heat
Running Amps 100 Amps
Minimum Dual Element Time Delay Fuse 100 Amp
Wire Size #1
Electrical Service 3 wire + ground
Electrical Specifications – Model -87
Voltage/Hz/Phase 240V/60Hz/1Phase/16kW Heat
Running Amps 85 Amps
Minimum Dual Element Time Delay Fuse 90 Amp
Wire Size #2
Electrical Service 3 wire + ground
