8514-234-001 REV N page 33
Temperature Pricing Option:
This option allows the user to require additional vend amounts be added based on the drying
temperature chosen by the customer. This pricing adder is effective only for the Base Vend Price (it does not
affect the Extend Dry Price). It allows a pricing adder separate for “Medium” and “Hot” temperature settings.
Example- A store owner has programmed the control for the following:
Vend Price $1.00
Vend Time 30 minutes
Extend Dry Price $.25
Extend Dry Time 8 minutes
Medium Adder $.25
Hot Adder $.50
In this case, the Vend Price is displayed as:
$1.00 if Low Temperature is chosen
$1.25 if Medium Temperature is chosen
$1.50 if Hot Temperature is chosen
When Temperature Pricing Adders are in place (user has chosen a higher value than $0.00), if the customer
attempts to change their temperature selection from a lower temperature to a higher one during a drying cycle,
there will be no change in the temperature selection. The higher temperature buttons are disabled until the
drying cycle is complete and a new Vend Price is required.
The figure below shows the sub menu options for Temperature Pricing:
Settings Options:
The Settings options allow for the user to make various programming changes to change how the control
operation affects the customer. See below for detailed information on each next level option.
1. “Decimal Point”: If the user programs the Decimal Point to “OFF”, control display will not show a decimal
point on any vend price values. The factory default is “ON”.
2. “Display Time”: If the user programs this value to “MIN”, then minutes only will be shown for the cycle
time. If it is programmed to “MIN+SEC”, then minutes and seconds will be shown. This also allows other
programming changes, involving time, to be made in either minute increments or minutes & seconds
increments, as desired.
3. “Temp Scale”: If the user programs this value to “F”, then the temperatures will be displayed in
Fahrenheit units. If it is programmed to “C”, then the temperature will be in Celsius units.
4. “Sounds”: If the user programs the Sounds to “OFF”, the control will not sound the enunciator at the end
of a dry cycle. The factory default is “ON”.
5. “Password”: If the user programs the password to any value other then 0000, the control will prompt the
user to enter a password (the programmed value) before manual programming can be accessed. The
factory default is “0000” (no password).
a. Note that if the user forgets the Password, it can be reset to factory default (no password), by
performing a hard reset on the control. Please refer to the appropriate section of this manual to
understand how to perform a hard reset.
b. The individual digits of the Password can be set by using the “Up” or “Down” buttons to change
the number that is flashing. Once the desired number is chosen for a single digit, press the
“Enter” button to move to the next one. Once all four desired digits are chosen, the “Enter”
button must be held down for 3 seconds to confirm that the complete password should be set.
6. “Language”: The control uses English for the default language of the customer prompts. Alternatively, the
user can choose Spanish, French, Malay, or Italian for the customer display prompts. However, all other
