Page #112 background imageLoading...
Page #112 background image
112
Part # 8533-090-001 7/21
-39 & -59 Models 50 Hz Parts
Key Part Number Description Quantity
* 9558-029-004 Strip, Terminal Marker -39 Models ..................................... 1
* 9558-033-001 Strip, Terminal Marker -59 Models ..................................... 1
* 9183-030-002 Filter EMI -59 only ............................................................ 1
1 8711-008-002 Transformer .................................................................... 1
* 8507-230-003 Instructions, Transformer Connect .................................... 1
2 9857-182-001 Ignition Control -39 Models ............................................... 2
2 9857-140-001 Ignition Control -59 Models ............................................... 2
* 9627-867-001 Harness-Ignition Control, Upper ........................................ 1
* 9627-867-002 Harness-Ignition Control, Lower ........................................ 1
* 9631-403-008 Wire Assembly High Voltage Upper ................................... 1
3 9631-403-009 Wire Assembly High Voltage Lower ................................... 1
4 9376-318-001 Motor .............................................................................. 2
* 9453-169-009 Pulley, Motor Drive ........................................................... 1
* 9627-864-002 Harness Motor Extension .................................................. 2
* 9506-590-001 Wiring Label Schematic/Diagram -39 models ...................... 1
* 9506-646-001 Wiring Label Schematic/Diagram -59 models ...................... 1
* 8514-233-001 Owner’s Manual ............................................................... 1
* 9866-004-009 Lint Drawer Assembly Upper/Lower -39 Models .................. 2
* 9866-004-001 Lint Drawer Assembly Upper/Lower -59 Models .................. 2
* 9435-003-011 Overlay, Lint drawer, Blue -39 Models ................................ 2
* 9435-003-009 Overlay, Lint drawer, Blue -59 Models ................................ 2
* 8514-253-001 OPerators Manual -39 Models ........................................... 1
* 8514-233-001 OPerators Manual -59 Models ........................................... 1
