-24VAC Control Parts Group

Key Part Number Description Quantity

* 9857-198-002 Controls Assy, Electronic Mounted With Membrane Switch, BLU ... 1

* 9857-198-004 Controls Assy, Electronic Mounted With Membrane Switch, BLK ... 1

1 9826-008-001 Trough Assembly .................................................................. 1

2 9032-062-002 Button-Push, Control, Blue ................................................... 2

2 9032-062-001 Button-Push, Control, Black................................................... 2

3 9538-166-011 Spacer-Metal, 4mm ............................................................... 4

4 9486-158-001 Retainer-Push Button ............................................................ 2

5 8640-424-002 Nut-Hex, Elastic stop, #4-40 ................................................ 4

6 8652-130-038 Terminal-Grounding clip ........................................................ 1

7 9534-365-001 Spring-Flat, Control ............................................................... 1

8 9545-008-001 Screw-Hex, #10B x 1/4 ......................................................... 2

9 9545-044-010 Screw-Hex, #10B x 1/4 ........................................................ 10

9 8641-582-005 Washer-External tooth, #6 ................................................... 10

10 9435-038-001 Overlay-Control, Coin, Black ................................................. 1

10 9435-038-002 Overlay-Control, Coin, Blue .................................................. 1

Note: Jumpers required if using 1.5 Control on Older Machines (P9 Connection)

* 8220-155-001 Wire Assy, Jumper, 30Lb Stack Coin .................................. 1

* 8220-155-002 Wire Assy, Jumper, 30Lb Stack Coin .................................. 1

117

Part # 8533-090-001 7/21
