Dexter Laundry WCAD Series Parts & Service Manual

C-Series Accessories
WC0300-XA10ECX 120 volts 60hz. Single Phase
WC0300-XA12ECX 208-240 volts 60hz. Single Phase or Three Phase
WC0350-XA12ECX 208-240 volts 60hz. Single Phase or Three Phase
WC0400-XA12ECX 208-240 volts 60hz Single Phase or Three Phase
WC0450-XA12ECX 208-240 volts 60hz Single Phase or Three Phase
WC0600-XA12ECX 208-240 volts 60hz Single Phase or Three Phase
Key Description T300 T350 T4 00 T450 T600 QTY
* Kit, Door Gasket Expander
(large)
9732-139-002 9732-139-002 9732-139-002 9732-139-002 9732-139-002
* Kit, Door Gasket Expander
(small)
9732-139-001 9732-139-001 9732-139-001 9732-139-001 9732-139-001
* Hose, Water Supply 3/8” I.D.
x 48”
9990-027-011 9990-027-011 9990-027-011 9990-027-011 9990-027-011 2
* Washer, Inlet Hose (furnished) 8641-242-000 8641-242-000 8641-242-000 8641-242-000 8641-242-000 2
* Strainer, Inlet Hose (furnished) 9565-003-001 9565-003-001 9565-003-001 9565-003-001 9565-003-001 2
* Bevel Washer for 5/8” bolt used
in installations using angle iron
bases
8641-586-002 8641-586-002 8641-586-002 8641-586-002 8641-586-002
* Bevel Washer for 3/4” bolt used
in installations using angle iron
bases
8641-586-003 8641-586-003 8641-586-003 8641-586-003 8641-586-003
* Sealing compound 85 3 8 -151- 0 01 853 8 -151-0 01 8538 -151-0 01 8538 -151-0 01 8 53 8 -151-0 01
* TOR X#20 8545-051-002 8545-051-002 8545-051-002 8545-051-002 8545-051-002
* Flow Restrictors (in dispenser ) 9475-002-002 9475-002-002 9475-002-002 9475-002-002 9475-002-002 2
* Battery (used on Control PCB) 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001
* VFD Filter options (1 phase)
120v
* VFD Filter options (3 phase)
* VFD Filter options (1 phase)
220VAC
* Coin Bearing & Seal Kit 9732-219-001 9732-219-002 9732-219-002 9732-219-004 9732-219-004
* Coin Op CD with OS2 Platform
for A Series Washers Only
9504-015-001 9504-015-001 9504-015-001 9504-015-001 9504-015-001
* Coin Box Assy, Blue Large 9807-099-002 9807-099-002 9807-099-002 9807-099-002 9807-099-002 1
Coin Box Assy, Black Large 9807-099-004 9807-099-004 9807-099-004 9807-099-004 9807-099-004 1
USB, Thumb Drive (Blank) 9150-045-001 9150-045-001 9150-045-001 9150-045-001 9150-045-001 1
USB, Thumb Drive, W/File 9150-045-002 9150-045-002 9150-045-002 9150-045-002 9150-045-002 1
Wiring Harness Part # by Model
Key Description T300 T350 T400 T450 T600 QTY
* Wiring Harness, Door Lock 9627-7 91- 003 9 627-791-0 0 3 9627-791- 0 03 9 627-791-0 0 3 9 627-791-0 0 4 1
* Wiring Harness,CoinDrop Mech 1
* Wiring Harness,
Drain,Thermo,DoorSol
9627-796-001 9627-796-001 9627-796-001 9627-796-001 9627-796-002 1
* Data Cable 9806-015-001 9806-015-001 9806-015-001 9806-015-001 9806-015-001 1
* Wiring Harness P20/P21 9627-793 -001 9627-793- 001 9627-7 9 3 - 001 9627-793- 0 01 9627-793- 0 01 1
* Wiring Harness P8/P16 9627-7 9 4- 0 01 9627-794 -001 9627-79 4 -0 01 9 627-794 - 001 9627-79 4 -0 01 1
* Wiring Harness WaterValve/P19 9627-795-003 9627-795-003 9627-795-003 9627-795-003 9627-795-004 1
* Wiring Harness LED PCB 9627-797- 001 9627-797-001 9627-797-001 9627-797-0 01 9627-797-001 1
Harness P5/Pressure -10 120VAC 9627-908- 001
Harness P5/Pressure 9627-908-002 9627-908-003 9627-908-004 9627-90 8-005 9627-908-007 1
* Wiring Assembly Yel. 32” 8220-064-023 8220-064-023 8220-064-023 8220-064-023 8220-064-023 2
* Wiring Assembly Red 7” 9631-381- 001 9631-381- 0 01 9631-3 81-001 9631-381-001 9631-381-018 3
* Wiring Assembly Vio. 24” 8220-118-001 2
* Wiring Assembly Jumper Yel 8220-123-001 8220-123-001 8220-123-001 8220-123-001 8220-123-001 1
* Wiring Assembly Blu/Red 8220-001-230 8220-001-230 8220-001-230 8220-001-230 8220-001-230 1
* Wiring Assembly Blk/Blu 8220-001-231 8220-001-231 8220-001-231 8220-001-231 8220-001-231 1
* Harness Power Terminal Block 9627-747-003 9627-747- 003 9627-747-0 03 9627-747-003 9627-747-003 1
Cord Assembly, Power -10
120VAC only
9802-037-009 1
Wire Assy Violet, 24” 8220-118-001 2
1
104 105
Part # 8533-080-001 12/15 Part # 8533-080-001 12/15
104 105
