Dexter Laundry WN0900 - Page 83

Key Description T-900 T1200 QTY
27 Cylinder Assy 9848-136- 001 9848-137-002
* Tub Front 9974-011-001 9974-011-002 1
* Gasket, Tub Front 9206-421-002 9206-421-002 1
* Ring Assy, Tub Mtg-Front Clamp 9950-055-001 9950-055-001 1
* Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 1
* Nut WCAD 3/8”-16 8640-415-001 8640-415-001 1
