Hardware Installation
TheVGAportisusedforconnectingaVGAmonitor.Connectthemonitor’s15-pin
D-shell cable connector to the VGA port. After you plug the monitor’s cable con-
nector into the VGA port, gently tighten the cable screws to hold the connector
inplace.
BIOS Setting
Congure the onboard VGA in the Advancedmenu of the BIOS. Referto chapter
3formoreinformation.
Driver Installation
Installthegraphicsdriver.Refertochapter4formoreinformation.
VGA Port
VGA
