Hardware Installation
Cooling Fan Connectors
Thefanconnectorsareusedtoconnectcoolingfans.Thecoolingfanswillprovide
adequateairowthroughoutthechassistopreventoverheatingtheCPUandsys-
temboardcomponents.
BIOS Setting
The Advanced menu (“PC Health Status” submenu) of the BIOS will display the
currentspeedofthecoolingfan.Refertochapter3formoreinformation.
3
1
Sense
Power
Ground
Systemfan
CPUfan
1
3
Sense
Power
Ground
