Step 2: Configure Serial/Parallel ATA in the Award BIOS
1. Power-on the system then press <Del> to enter the main menu
of the Award BIOS.
2. Select the Integrated Peripherals submenu - “OnChip IDE
Device” section of the BIOS.
3. Set the “RAID Enable” field to “Enabled”.
4. Enable
the RAID function of the Serial/Parallel ATA drives you
want to configure as RAID.
5. Press <Esc> to return to the main menu of the BIOS setup
utility. Select “Save & Exit Setup” and press <Enter>.
6. Type <Y> and press <Enter>.
7. Reboot the system.
OnChip IDE Channel 0
Primary Master PIO
Primary Slave PIO
Primary Master UDMA
Primary Slave UDMA
OnChip IDE Channel 1
Secondary Master PIO
Secondary Slave PIO
Secondary Master UDMA
Secondary Slave UDMA
IDE DMA Transfer Access
Serial-ATA Controller
IDE Prefetch Mode
IDE HDD Block Mode
****************
Onboard RAID Setting
****************
RAID Enable
x IDE Primary Master RAID
x IDE Primary Slave RAID
x IDE Secndry Master RAID
x IDE Secndry Slave RAID
x SATA 1 Primary RAID
x SATA 1 Secondary RAID
x SATA 2 Primary RAID
x SATA 2 Secondary RAID
