141
7
SLI Technology
4. Secure the graphics card with the screw you removed in step 2.
5. Remove the screw of the bracket that is opposite the PCIE 3
slot then remove the bracket.
6. Align the graphics card above the PCIE 3 slot then press it
down firmly until it is completely seated in the slot.
7. Secure the graphics card with the screw you removed in step 5.
PCI Express x16
graphics card
PCIE 3
To Next Page
