Hardware Installation
We strongly recommend that you install the PCI Express slots with
the corresponding PCI Express cards shown in the table below.
PCI Express Cards
Graphics card
LAN, TV or RAID card
PCIE 1: x16 slot
PCIE 3: x2 slot
PCIE 1
16x
8x
1-2 On
2-3 On
PCIE 3
2x
-
Important:
When the jumpers are set to 2-3 On, the system board only
support one graphics card. Install the graphics card onto the
PCIE 1 slot. Do not install any card on PCIE 3. This is a chipset
limitation therefore if there is a card installed on PCIE 3, the
system might fail to boot.
The settings below are for INFINITY NF ULTRAII-M2, INFINITY
NFII-M2 and INFINITY NF4XII-M2 system boards.
