DGTEC DG-1008i - Main Unit Control Layout

11
Location of Controls
12
34
5
6
7
8
9
10
11
12
FUNCTION
CLOCK
ADJ.
PAI RIN G
SNOOZEALARM REPEAT
13
14
15 16 17 18
252423222120
19
26
VOL +VOL -
1. EJECT button
2. Remote sensor
3. LCD display
4. STANDBY button
5. Power LED
6. iPod door
7. Control key door
8. USB slot
9. SD/MMC card slot
10. Headphone jack
11. LINE-OUT jack
12. AUX IN jack
13. FM antenna
14. DC IN jack
15. FUNCTION button
16. STOP
17. SKIP BACKWARD
18. SKIP FORWARD
19. PLAY/PAUSE
20. PAIRING button
21. CLOCK/ADJ. button
22. ALARM button
23. SNOOZE button
24. REPEAT button
25. VOL – button
26. VOL + button
Wireless Main Unit
