1190 Sr Owner’s Manual
9
Assembly Instructions
sure to include a flat and split lock washer on each bolt.
5-9. Install seat back pad on the seat frame using the four M6 x 15mm screws,
making sure to include a flat and split lock washer on each bolt.
Step 6: Seat Back Cover
Install the seat back cover over the back of the seat using the four M6 x 15mm
screws.
Step 7: Pedal Assembly
Use a 15mm or adjustable open-end wrench to firmly tighten the pedals to the
cranks. The left and right pedals are different and are denoted as right or left (R
or L) on the top & bottom of each pedal. Note that the left pedal will thread
counter-clockwise.
Note: Pedals should be re-tightened after the first 10 hours of use as they may
become loose until they have fully seated to the crank.
1190SROM 9/22/06 1:51 PM Page 11
